SMARTIA CTP – Thermal positive plate. UV ink resistence

Thermal positive plate designed to avoid baking processes . High resistance on UV inks, metallic inks and substitute addictive alcohol.

Technical characteristics

Plate type	CTP Double Layer – Positive working with high resistance to UV inks
Size	Max. GE 1350mm
Gauges	0,15 / 0,20 / 0,25 / 0,30 / 0,40
Color	Dark blue . Hight contrast after developer
Spectral sensitivity	800 – 840 nm
Energy required	100-120 mJ/cm2
Resolution	AM 1% – 99% lpi @ 450 lpi FM 20 microns stochastic
Compatible platesetter	All Thermal CTPs systems on market
Developer	Platea D11 Temperature \| 23 ± 2 ºC Time \| 25 ± 5 seconds Replanishment rate \| 120 ml/m2 Anti-ox on \| 100 ml/h Anti-ox off \| 100 ml/h
Replenisher	Platea RD1 Replanishment rate \| 50 – 70 ml/m2 anti-ox on \| 40 – 60 ml/h anti-ox off \| 40 – 60 ml/h
Gumming	Plategum S1 \| Finishing gum GUM RTU \| Ready to use processor machine gum
Baking	Plategum TERM \| Baking gum Baking conditions Static oven \| 180º – 220º C @ 5 min On-line oven \| 220º – 240º C @ 3 min
Safelight	Coating properties are not affected up to 3 hours under white/day light
Shelf Life	24 months if storage conditions are respected (5º-30ºC and 30-80% rH)
Run Length	Up to 150.000 Copies – UV Inks Up to 300.000 Copies – Conventional Inks NOTE: The results obtained may vary depending on the conditions of the press, papers, inks or if the use is outside our recommended values.
